Standard Chassis
Diesel Engine
Deutz TCD4.1 (115KW)
Transmission and Converter
Manufacturer: USA DANA
Model： DANA R32000
Drive axle (With spring brake)
Manufacturer: USA DANA
Type: Multi-discs wet hydraulic service brake, spring brake+hydraulic release; spring brake+hydraulic release parking brake;
модель DANA 113
Hydraulic system
Type: steering. Service brake, safety brake system
Remark: PERMCO gear pump; main hydraulic components from MICO or Rexroth Bosch
Exhaust purifier: Oxide catalyst system+ silencer
Central Articulation pin shaft
Material DC12(40Cr)φ60×146
Main Components and Build-up List
| S/N | Name of Components | Model | Supplier |
| 2.1 | Transmission: Mainly imported brands | ||
| 2.1.1 | Diesel engine | TCD4.1 115KW | Deutz TCD4.1 115KW |
| 2.1.2 | Transmission/Converter | R32000+C271 | USA DANA |
| 2.1.3 | Drive axle (F+R) | 113 | USA DANA |
| 2.1.4 | Transfer shaft | —— | Made in China |
| 2.1.5 | Exhaust purifier | Made-in-China | |
| 2.1.6 | Silencer | Made-in-China | |
| 2.1.7 | Wheel rim | 10.0-20 | Made-in-China |
| 2.18 | Tyres | 12.00-20 cut-resistance | Made-in-China |
| 2.2 | Frame: Made-in-China | ||
| 2.3 | Standard fittings: Made-in-China | ||
| 2.4 | Hydraulic system | ||
| 2.4.1 | Gear pump | Imported | |
| 2.4.2 | Charging valve | 06－463－230 | USA MICO |
| 2.4.3 | Footage valve | 06－466－210 | USA MICO |
| 2.4.4 | Manual brake solenoid valve | —— | Made-in-China |
| 2.4.5 | Accumulator | 0.75L | |
| 2.4.6 | Pressure Switch | 24V 100 bar | Imported |
| 2.4.7 | Other hydraulic components: Made-in-China | ||
| 2.5 | Electric system: engine/converter gauges imported brand, others made-in-China | ||
| 2.6 | Other mechanism made in China | ||
| 2.7 | Cabin: made in China; |
